Accuton ceramic bass, C173-6-096

C173-6-096
742.45 € Без НДС
920.64 € с НДС для покупателей из ЕС

Accuton ceramic bass, C173-6-096

Количество
В наличии

Ceramic Bass-Midrange Driver

Domematerial Ceramic
Application Bass‑Midrange
Overall diameter 173 mm
Cutout Diameter/Square 146 mm
Overall depth 102 mm
Motor assembly depth 49.5 mm
Motor assembly diameter 120 mm

Vented box design parameters

Vb: 8L, Fres: 25Hz with passive radiator, -18dB @ 25Hz, Q: 0.38 (optimal A/V alignment)

Vb: 4.1L, Port diameter: 50mm, Length: 170mm, Fres: 82Hz, F-3dB: 85Hz, Q: 0.50 (typical A/V alignment)

Vb: 11L, Port diameter: 50mm, Length: 150mm, Fres: 53Hz, F-3dB: 55Hz, Q: 0.34 (extended bass)

Closed Box design parameters

Vb: 4.1L, -18dB @ 40Hz, F-3dB: 175Hz, Q: 0.50 (clean transient response)

Vb: 11L, -15dB @ 40Hz, F-3dB: 170Hz, Q: 0.38 (extended bass for active systems)


Mechanical Data
SpecificationValueUnit
Overall diameter 158 mm
Cutout Diameter/Square 137 mm
Min. frontplate thickness 6 mm
Overall depth 90 mm
Motor assembly depth 42 mm
Motor assembly diameter 120 mm
Screwfitting DIN 7984, Ø 4,50 mm
Terminal + : 6.3 x 0.8 / - : 4.8 x 0.8 mm
Shipping weight (pair) 5.2 kg
Shipping box size (pair) 180 / 180 / 240 mm
Thiele/Small parameters
SpecificationValueUnit
Sensitivity (2.83V / 1m) Lp 88 dB
DC-resistance Re 6.07 Ohm
Resonance frequency Fs 31 Hz
Equivalent volume of air Vas 25.7 L
Mechanical Q Qms 5.09
Electrical Q Qes 0.29
Total Q Qts 0.28
Effective piston area Sd 113 cm²
Moving mass Mms 18.5 g
Suspension compliance Cms 1.42 mm/N
Mechanical resistance Rms 0.71 kg*s
voice coil parameters
SpecificationValueUnit
Power handling P 120 Watt
Linear excursion Xmax +/- 5 mm
Voice coil diameter 38 mm
Voice coil former material Ti
Voice coil material Cu
Voice coil inductance Le 0.77 mH
Force factor BI 8.7 N/A
Motor type überhängig
Ferrofluid filling Nein

Ceramic Bass-Midrange Driver

Domematerial Ceramic
Application Bass‑Midrange
Overall diameter 173 mm
Cutout Diameter/Square 146 mm
Overall depth 102 mm
Motor assembly depth 49.5 mm
Motor assembly diameter 120 mm

Vented box design parameters

Vb: 8L, Fres: 25Hz with passive radiator, -18dB @ 25Hz, Q: 0.38 (optimal A/V alignment)

Vb: 4.1L, Port diameter: 50mm, Length: 170mm, Fres: 82Hz, F-3dB: 85Hz, Q: 0.50 (typical A/V alignment)

Vb: 11L, Port diameter: 50mm, Length: 150mm, Fres: 53Hz, F-3dB: 55Hz, Q: 0.34 (extended bass)

Closed Box design parameters

Vb: 4.1L, -18dB @ 40Hz, F-3dB: 175Hz, Q: 0.50 (clean transient response)

Vb: 11L, -15dB @ 40Hz, F-3dB: 170Hz, Q: 0.38 (extended bass for active systems)


Mechanical Data
SpecificationValueUnit
Overall diameter 158 mm
Cutout Diameter/Square 137 mm
Min. frontplate thickness 6 mm
Overall depth 90 mm
Motor assembly depth 42 mm
Motor assembly diameter 120 mm
Screwfitting DIN 7984, Ø 4,50 mm
Terminal + : 6.3 x 0.8 / - : 4.8 x 0.8 mm
Shipping weight (pair) 5.2 kg
Shipping box size (pair) 180 / 180 / 240 mm
Thiele/Small parameters
SpecificationValueUnit
Sensitivity (2.83V / 1m) Lp 88 dB
DC-resistance Re 6.07 Ohm
Resonance frequency Fs 31 Hz
Equivalent volume of air Vas 25.7 L
Mechanical Q Qms 5.09
Electrical Q Qes 0.29
Total Q Qts 0.28
Effective piston area Sd 113 cm²
Moving mass Mms 18.5 g
Suspension compliance Cms 1.42 mm/N
Mechanical resistance Rms 0.71 kg*s
voice coil parameters
SpecificationValueUnit
Power handling P 120 Watt
Linear excursion Xmax +/- 5 mm
Voice coil diameter 38 mm
Voice coil former material Ti
Voice coil material Cu
Voice coil inductance Le 0.77 mH
Force factor BI 8.7 N/A
Motor type überhängig
Ferrofluid filling Nein
